Merrithew™ Pilates SPX® Max Plus™ Reformer Bundle

Description

The Merrithew SPX Max Plus Reformer Bundle is the most advanced model in the SPX family, a commercial-grade STOTT PILATES reformer and virtual Cadillac in one space-saving frame. Its vertical frame with traveling pulleys and a patented retractable rope system deliver variable angles of resistance and three-dimensional movement that replicates everyday activities.

Built for studio owners, instructors, and serious home users, it combines full reformer functionality with tower and Cadillac-style exercises, making it suitable for all fitness levels, rehabilitation, and athletic training.

This bundle adds the accessories that expand the machine’s repertoire: a Mat Converter, a Reformer Box with footstrap, a Padded Platform Extender, and a Maple Roll-Up Pole, a value of over $1,150 compared to buying them separately.

The SPX Max Plus is also a CE Marked Class I Medical Device in conformity with the European Medical Device Regulation (EU) 2017/745 (MDR), so it can be formally used in hospitals and healthcare settings by medical professionals.

Who is it built for and when it makes sense

• Studio owners and instructors who want both reformer and Cadillac/tower functionality in one machine, with the variable resistance angles of the vertical frame and traveling pulleys.
• Serious home practitioners who want the most capable SPX reformer with full tower functionality in a compact, commercial-grade frame.
• Rehab, clinical, and athletic training. As a CE-marked Class I medical device with three-dimensional resistance, it suits rehabilitation and performance work.

When it’s not the right fit

• If you only need a standard reformer and won’t use the vertical frame or tower exercises, a standard SPX Max bundle may be a better-value choice.
• If you have very limited ceiling height. The vertical frame needs a minimum ceiling height of 77 in (195.6 cm) to install, and standing platform exercises need about 97.5 in (2.48 m).
• If you want a machine you can fold away. It does not fold; it is stackable only when the vertical frame is removed.

Key Features

Materials

C-channel aluminum rails, durable vinyl upholstery over dense EVA foam, and a 1 in (25 mm) thick wooden standing platform. The included Roll-Up Pole and roll-down bar are maple.

Resistance system

Reformer: High Precision Springs Package, 5 reformer springs (3 at 100%, 1 at 50%, 1 at 25%), with 5 neoprene spring covers for noise reduction.

Vertical frame: 2 push-thru springs, 2 roll-down springs (with maple roll-down bar), 2 arm springs (with foam grip handles), and 2 leg springs (with padded long spine straps), plus 2 extension straps and 2 traveling pulleys for variable angles of resistance.

Upholstery colors

Available in 6 standard colors: Black, Gunmetal Gray, Sierra Brick, Eclipse, and Purple Impulse. Plus 20+ custom colors available on request. Email sales@pilatesmatters.com for custom color options.

What’s included

Specifications

Space requirements

The reformer measures approximately 99.5 in x 26 in (252.7 cm x 66 cm), with a vertical frame about 174 cm tall. You also need clear space around it to move freely. As a practical guide, plan for a room that offers:

• Length: Allow extra room beyond each end of the 99.5 in (2.53 m) frame for arm and leg extensions, the box, and the platform extender.
• Width: Leave room on both sides of the 26 in (66 cm) frame for lateral movements and to get on and off safely.
• Ceiling height: At least 77 in (195.6 cm) to install the vertical frame, and at least 97.5 in (2.48 m) for standing platform exercises (based on a 5’8" user, taller users need more).

Who it fits (height)

Merrithew does not publish an official user height range for the SPX Max Plus. As a practical guide:

• The 38.5 in (98 cm) carriage comfortably accommodates most adult users.
• Taller users, or those with a long torso who find full extension restrictive, can add a Reformer Extension Upgrade for +6 in (15 cm) of length (available separately).

Assembly

• Minimal assembly is required for the reformer; the vertical frame attaches to the reformer.
• Built-in easy-roll wheels let you reposition it once set up.
• An Owner’s manual is available for setup, proper use, and maintenance.

For assembly help, see our Assembly & Installation page for support options, including professional installation service.

Moving and storage

• This reformer does not fold, but easy-roll wheels on both ends make it simple to move and reposition.
• It is stackable when the vertical frame is removed; shoulder rests slide into frame brackets and reinforced pulleybars detach without disengaging the ropes.
• A rolling base is available separately for added convenience when moving stacked reformers.

Replacement parts, accessories and maintenance

As an authorized Merrithew retailer, we carry replacement parts, accessories, and upgrades for this reformer.

• Pilates Accessories such as replacement springs, ropes, straps, loops, spring covers, and other wear parts.
• Pilates Upgrades including the Reformer Extension Upgrade and High-Precision Gearbar.

For any maintenance questions or part availability, contact our team directly at sales@pilatesmatters.com or +1 (402) 726-1797.

Maintenance Requirements:

• Carriage wheels & rails: keep clean and free of debris to keep the carriage gliding smoothly.
• Upholstery: wipe down with a damp cloth. For deeper stains, use a small amount of neutral soap diluted in water.
• Springs: inspect periodically and replace worn springs to maintain proper tension and safety.

Warranty

• Limited lifetime warranty: aluminum rails, components of the frame and related welding, standard gearbar, and footbar mechanisms (excluding the rubber / Comfort Footbar)
• 90 days: upholstery
• 1 year: ropes, straps, spring clips, plastic pulley bar receptacle sleeves, comfort footbar, spring covers, and plastic spring holders
• 2 years: all other Reformer components

Visit our Warranty page for full and up-to-date details.

Shipping & Delivery

• Please note: Merrithew products are excluded from free US shipping (and from shipping to Alaska, Hawaii, and Puerto Rico).
• Large equipment ships via freight carrier, carefully packed in a cardboard or plywood box.
• Standard delivery is curbside, as close to your entrance or garage as possible. The driver does not unload inside. Plan to have two people available to bring it in.
• The carrier will call ahead to schedule your delivery. Missing your scheduled window may result in additional charges.
• Tracking is sent via email once your order ships. Questions? Contact us at sales@pilatesmatters.com.

Before signing for delivery: inspect the outer box and note any visible damage on the waybill. Damage not noted at delivery cannot be claimed later. For damaged items, send photos to returns@pilatesmatters.com.

Returns & Cancellations

• Cancellations are accepted within 24 hours of ordering. After 24 hours we’ll do our best but cannot guarantee cancellation. Shipped orders cannot be cancelled or returned.
• This product is final sale. As with all Merrithew equipment (excluding accessories), this reformer is not eligible for returns. Please review your order carefully before purchasing.

If you have any questions before buying, contact our team at sales@pilatesmatters.com or +1 (402) 726-1797.
